The MC1408 series of 8-bit monolithic digital-to-analog converters provide high-speed performance with low cost. They are designed for use where the output current is a linear product of an 8-bit digital word and an analog reference voltage.
Features:-
• Fast settling time — 70ns (typ)
• Relative accuracy ±0.19% (max error)
• Non-inverting digital inputs are TTL and CMOS compatible
• High-speed multiplying rate 4.0mA/µs (input slew)
• Output voltage swing +0.5V to –5.0V
• Standard supply voltages +5.0V and –5.0V to –15V
• Military qualifications pending
Specifications:-
| Symbol | Parameters | Rating | Units |
| VCC | Positive power supply voltage | 5.5 | V |
| VEE | Negative power supply voltage | –16.5 | V |
| V5-V12 | Digital input voltage | 0 to VCC | V |
| VO | Applied output voltage | –5.2 to +18 | V |
| I14 | Reference current | 5 | m A |
| V14,V15 | Reference amplifier inputs | VEE to VCC | |
| PD | Maximum power dissipation, TA = 25°C (still-air) | ||
| F package | 1190 | m W | |
| N package | 1450 | m W | |
| D package | 1080 | m W | |
| TSOLD | Lead soldering temperature (10 sec) | 300 | °C |
| TA | Operating temperature range | 300 | °C |
| MC1408 | 0 to +75 | °C | |
| TSTG | Storage temperature range | -65 to +150 | °C |
